EFOIL SYSTEM.
input power(watt): 8000w
power output at shaft (in watts): 6000w
nominal voltage(v): 52v
maximum current(amps): 120a
type of motor: brushles waterproof motor
motor speed: 7000 rpm
motor power(hp): 8kw
protection(ips7/68/...): ip68
propeller diameter(mm): 150mm
propeller protection(mm): 168mm
type of cooling: water cooling
PACKAGE SIZE 7 GROSS NET.
overall package(mm): 1780mm*780mm*470mm
battery case (mm): 450mm*150mm
gross weight(kg): carton 52kg,wooden cases 83kg,battery only package 21kg
net weight(kg): plate 11.5kg,battery 18kg,hydrofoil 8.5kg
FLASH CONTROLLER.
communication type: 2.4g
speed control: main gear, GPS speed display, cruise
running time: 30hours
protection level: ip68
)
)
)
)
)
)
